Mini Portable Mesh Nebulizer

The Portable Mesh Nebulizer provides a practical way to administer prescribed liquid medication that is compatible with the device. Its mesh technology converts medication into a fine aerosol, with a mass median aerodynamic diameter (MMAD) of 3.7 ± 1 µm and a nebulization rate of at least 0.20 mL/min, according to the specifications printed on the packaging.

The device features a compact, easy-to-carry design, a translucent medication chamber, and simple one-button operation. It supports a 5V, 1A USB power source and has a stated noise level of 50 dB or less. The set includes an adult mask, a child mask, and a mouthpiece, allowing the appropriate inhalation interface to be selected as directed by a healthcare professional.

• Mesh technology converts compatible liquid medication into a fine aerosol.

• Simple one-button operation.

• Compact design for convenient carrying and storage.

• Supports a 5V, 1A USB power source.

• Translucent medication chamber allows the liquid level to be viewed.

• Adult mask, child mask, and mouthpiece provide different inhalation options.

• Nebulization rate of at least 0.20 mL/min.

• Residual medication volume of no more than 0.5 mL, according to the packaging specifications.

• Noise level of 50 dB or less.

• Mass median aerodynamic diameter (MMAD) of 3.7 ± 1 µm.

• Converts prescribed liquid medication that is compatible with the device into an aerosol inhaled through a face mask or mouthpiece.

• Administers inhaled medication as part of a healthcare professional’s treatment plan.

• For use at home or while travelling when a suitable power source is available.

• Allows an appropriate adult or child inhalation interface to be used according to clinical advice and the device instructions, with adult supervision for children.

1. Read the device manual and wash your hands before preparing a treatment.
2. Check that the components are clean, undamaged, and correctly assembled.
3. Open the medication chamber and add the prescribed dose of a compatible medication without exceeding the maximum fill mark.
4. Close the chamber securely and attach the appropriate mask or mouthpiece.
5. Connect the device to a compatible 5V, 1A USB power source using a suitable cable.
6. Sit upright in a comfortable position. Place the mask over your nose and mouth, or seal your lips around the mouthpiece.
7. Press the power button and breathe calmly as directed by your healthcare professional. Maintain the operating position specified in the device manual and avoid tilting that could cause leakage.
8. Switch off the device and disconnect the power source when treatment is complete.
9. Clean the washable components after each use according to the device manual, and allow them to dry completely before storage.

• 1 × Portable mesh nebulizer.

• 1 × Adult mask.

• 1 × Child mask.

• 1 × Mouthpiece.

• Use only medication and doses prescribed by a healthcare professional, after confirming compatibility with this device.

• Do not change the dose or mix medications without medical advice.

• Use a power source that matches the device specifications: DC 5V, 1A.

• Do not immerse the main unit or USB port in water. Disconnect the power source before cleaning.

• Do not touch or wipe the mesh membrane with a cloth, and do not insert needles or hard objects into its openings.

• Follow the cleaning and disinfection methods specified in the device manual. Do not boil components or use chemicals unless the manual permits it.

• Do not exceed the medication chamber’s maximum fill level, and avoid tilting that could cause leakage.

• Children must use the device under adult supervision.

• Do not use the device if it is damaged or if the cable or power source is faulty.

• Stop use and consult a healthcare professional if irritation or unusual symptoms occur during treatment.

• Store In Dry Location Away From Moisture And Humidity

• Operating Temperature: 5°C To 45°C

• Storage Temperature: -10°C To 60°C

• Relative Humidity: ≤80% Non-Condensing

• Keep USB Port Covered To Prevent Dust Accumulation

• Store Separately From Sharp Objects To Protect Mesh Membrane

• Charge Device Every Two Months During Long-Term Storage
